Transmission Type
DSG 7 DQ200
Component
TCU / Mechatronics Control Unit
Condition
New
Manufacturer
LuK
Origin
Manufactured in China
Warranty
24 Months
New TCU for DQ200 Mechatronics
This 0AM927769E unit is a new transmission control unit for selected 7-speed DSG DQ200 mechatronics systems used in Volkswagen Group vehicles. Your reference product confirms this TCU number in combination with DQ200 mechatronics, and external listings also associate it with dry-clutch DSG7 applications up to 250 Nm. [web:111][web:294]
OEM Part Numbers
Main OEM Number:
0AM927769E
Related Mechatronics / Hydraulic References:
0AM325025E • 0AM325025D • 0AM325025H • 0AM325025J • 0AM325065N • 0AM325065L • 0AM325065S • 0AM325065T • 0AM325065AB
Always Verify the Exact Part Number
Before ordering, compare the OEM number on your original control unit and confirm it matches 0AM927769E. This product is supplied as the TCU only and does not include the hydraulic block, so compatibility must be checked carefully before purchase.
Technical Specifications
Transmission Type:
7-Speed DSG DQ200
Component Type:
Transmission Control Unit (TCU)
System:
DQ200 Mechatronics
Supplied As:
TCU only, without hydraulic block
Clutch Type:
Dry Clutch DSG System
Torque Range:
For DQ200 applications up to 250 Nm
Installation Note:
Programming / adaptation may be required after installation
Warranty Period:
24 Months
Product Description
This new 0AM927769E transmission control unit is designed for selected DSG 7-speed DQ200 mechatronics systems used in VW Group vehicles. It is supplied as the electronic control unit only and is intended as a replacement for a defective original TCU when the hydraulic block is not included. [web:111][web:294][web:305]
What This TCU Does
- Controls electronic functions of the DQ200 mechatronics system
- Processes gearbox-related sensor and operating data
- Supports shift management and clutch control logic
- Works with the mechatronics assembly in compatible DSG7 applications
- Serves as a replacement for faulty or non-communicating original TCU units
Important Product Note
This product includes the TCU only. It is supplied without hydraulic block, so it is not a complete mechatronics unit. Your reference product page is for a complete mechatronic assembly, while this listing is only for the electronic control unit portion. [web:111]
Vehicle Compatibility
This control unit is intended for selected Volkswagen Group vehicles equipped with 7-speed DSG DQ200 transmission. External listings for 0AM927769E commonly associate it with VW, Audi, Škoda and SEAT vehicles using dry-clutch DQ200 systems, with compatibility typically depending on part number, software version and gearbox configuration. [web:294][web:305]
Suitable for Selected Models Such As
- Audi A1 / S1
- Audi A3
- Audi Q3
- VW Golf
- VW Beetle
- VW Jetta
- VW Caddy
- VW Passat
- VW Polo
- VW Scirocco
- VW Sharan
- VW Touran
- Škoda Fabia
- Škoda Octavia
- Škoda Superb
- Škoda Yeti
- SEAT Altea / XL
- SEAT Ibiza
- SEAT Leon
Compatibility Check Recommended
DQ200 applications can differ by software version, mechatronics configuration and production period. If you are unsure, send us your VIN number together with the part number from your original TCU for verification before ordering.
Common Fault Codes & Symptoms
A defective DQ200 transmission control unit can contribute to gear selection problems, warning messages, loss of communication and emergency running mode. Public repair and parts sources for 0AM927769E also note that replacement units may require programming or proper matching to the gearbox system after installation. [web:94][web:305][web:306]
-
No communication TCU not responding correctly during diagnostics
-
Gear selection fault Transmission cannot shift correctly
-
Limp mode Gearbox enters emergency operating mode
-
Start inhibition Vehicle may not start if transmission status is not recognized correctly
-
Programming required Replacement unit needs matching or adaptation
- Warning message for gearbox malfunction on dashboard
- Jerking, delayed engagement or unstable shifting behaviour
- Loss of odd or even gear operation depending on system condition
Diagnostic Note
Fault symptoms alone do not always prove that the TCU is defective, because hydraulic, clutch, wiring or sensor-related problems can produce similar DSG behaviour. Proper diagnosis before replacement is strongly recommended.
Installation & Service Notes
Recommended Steps
- Check the exact OEM number on the original control unit
- Confirm that the gearbox is a DSG 7 DQ200 version
- Verify that you need the TCU only and not a complete mechatronics unit
- Inspect the existing mechatronics assembly and hydraulic block condition
- Install the replacement unit carefully using professional workshop procedures
- Carry out coding, programming or adaptation if required
- Perform diagnostic checks and test gearbox operation after installation
Important Installation Note
This is an electronic transmission component. Incorrect installation, wrong software matching or incompatible mechatronics configuration can prevent the gearbox from operating correctly. Installation by a DSG specialist is strongly recommended.
Why TCU Replacement Matters
1. Restores Electronic Control
A properly functioning TCU is essential for communication and shift management in the DQ200 system.
2. Supports Correct Shifting
The control unit helps manage clutch and gear selection logic within the DSG transmission system.
3. Helps Resolve Control Faults
Replacing a defective original TCU can help restore gearbox control when the electronics are the source of the fault.
4. Flexible Repair Option
A TCU-only replacement can be useful when the hydraulic block does not need to be replaced.
Quality Assurance & Warranty
24-Month Warranty: This new DQ200 transmission control unit is supplied with a 24-month functionality warranty under normal operating conditions.
Warranty Coverage Includes:
- Manufacturing defects of the supplied TCU
- Material or electronic defects under normal use
- Functional defects of the replacement control unit itself
Warranty Exclusions:
- Incorrect installation
- Improper programming, coding or adaptation
- Damage caused by defective hydraulic block, wiring or gearbox-related faults
- Physical damage or misuse
Questions or Need Help?
We can help verify compatibility and advise whether this 0AM927769E TCU is suitable for your gearbox.
Contact
Important Purchase Information
- Please compare the OEM number on your original unit before purchase
- This product includes the TCU only and does not include the hydraulic block
- Programming, coding or adaptation may be required after installation
- Professional installation is recommended
- Photos are for illustrative purposes only
- Worldwide shipping is available
- If your country is not listed at checkout, contact us for manual order processing
- Please check carefully whether this product matches your vehicle and gearbox version before ordering
