• Haldex control valve N373 4.gen.
  • N373 photo
  • Solenoid haldex clutch
  • 4. gen. haldex valve 0AY598554C, 0BR598554C, 0BS598554C, 109593,
1 4

Borgwarner

N373 Haldex control valve 4.gen. Used

N373 Haldex control valve 4.gen. Used

€129,90 EUR
€129,90 EUR
Sale Sold out
  • Warranty
  • Online Support
  • Express Shipping
N373 Haldex Control Valve 4.Gen. | Used

N373 Haldex Control Valve 4.Gen. Used

Part Number: N373 / 109593

Original clutch operating angle control valve for 4th generation Haldex AWD systems

System Type Haldex AWD 4th Generation
Component Control Valve N373
Condition Used Fully Functional
Manufacturer BorgWarner
Function Clutch Operating Angle Control
Warranty 12 Months
Tested & Ready for Installation This original N373 control valve is designed for 4th generation Haldex couplings and is responsible for controlling oil flow and clutch operating behaviour inside the AWD unit. [web:179][web:182]

OEM Part Numbers

Main OEM Number:

109593

Related Reference Numbers:

BW109593 • 0BR598554C • 0BS598554C • 0AY598554C • 22150003

Always Verify Your Part Number Before placing an order, compare the OEM number on your original valve and confirm it matches the N373 references listed above. Exact fitment should always be checked before purchase. [web:179]

Technical Specifications

System Type:
Haldex AWD 4th Generation
Component:
Clutch Operating Angle Control Valve N373
Application:
Selected AWD vehicles with 4th Gen Haldex coupling
Manufacturer:
BorgWarner
OEM Number:
109593
Reference Numbers:
BW109593 / 0BR598554C / 0BS598554C / 0AY598554C / 22150003
Part Condition:
Used
Valve Type:
Proportional Oil Control Valve
System Function:
Controls oil routing and clutch operating angle in Haldex unit
Warranty Period:
12 Months

Product Description

This original used N373 valve is designed for 4th generation Haldex AWD systems. It is a precision oil control valve used to regulate clutch operating behaviour inside the Haldex coupling and plays an important role in correct all-wheel-drive function. [web:179][web:182]

What This Valve Does

  • Controls oil flow between internal Haldex channels
  • Regulates clutch operating angle and coupling behaviour
  • Supports correct AWD engagement and disengagement
  • Helps maintain proper hydraulic control inside the Haldex unit
  • Serves as a replacement for defective original N373 valves
Installation Information Because the N373 valve is a precision hydraulic control component, correct diagnosis should be confirmed before replacement. Careful handling during installation is important, as damage or contamination can affect valve performance. [web:182]

Vehicle Compatibility

This valve is suitable for selected vehicles equipped with 4th generation Haldex coupling. Publicly listed compatibility includes multiple models from Audi, VW, Škoda, SEAT, Volvo, Land Rover, Ford, Opel and Saab using the Haldex Gen 4 AWD system. [web:179]

Suitable for the Following Vehicle Models

  • Audi A1 Quattro (2011 - 2014)
  • Audi A3 / S3 / RS3 Quattro (2008 - 2013)
  • Audi Q3 / RSQ3 Quattro (2012 - 2014)
  • Audi TT Quattro (2007 - 2014)
  • VW Caddy 4Motion (2008 - 2015)
  • VW Golf VI 4Motion (2008 - 2013)
  • VW Tiguan (2008 - 2013)
  • VW Passat B6 / B7 / CC 4Motion (2008 - 2016)
  • VW Sharan II 4Motion (2008 - 2016)
  • VW Transporter T5 4Motion (2008 - 2015)
  • Škoda Octavia II FL 4x4 (2008 - 2014)
  • Škoda Superb II 4x4 (2008 - 2015)
  • Škoda Yeti 4x4 (2008 - 2014)
  • SEAT Alhambra (2008 - 2015)
  • SEAT Altea 4x4 (2009 - 2015)
  • Volvo XC60 / XC70 / XC90 / S80 / V70 (2008 - 2014)
  • Volvo S60 / V60 AWD (2010 - 2014)
  • Land Rover Freelander 2 (2009 - 2015)
  • Range Rover Evoque (2012 - 2014)
  • Ford Kuga AWD (2008 - 2012)
  • Opel Insignia AWD (2009 - 2019)
  • Saab 9-3 / 9-5 AWD (2008 - 2011)
Not Sure About Compatibility? If you are unsure whether this valve fits your vehicle, send us your VIN number or the OEM number from your original Haldex component. We will help confirm compatibility before you order.

Common Fault Codes & Symptoms

A defective N373 valve can affect oil control inside the Haldex unit and may contribute to AWD malfunction, abnormal clutch behaviour or warning messages. Publicly referenced fault information connects this valve with the diagnostic code 02248 and with issues related to clutch control and oil regulation. [web:179][web:182][web:188]

  • 02248 Valve for Controlling Clutch Operating Angle (N373) – intermittent or defective
  • P0961 / P0962 Control solenoid / algorithm-related fault associated with valve operation
  • Restricted oil control Incorrect oil routing inside the Haldex coupling
  • Clutch control fault Improper engagement or release behaviour of the clutch pack
  • Rear axle engagement problems
  • AWD not working correctly or engaging late
  • Unwanted clutch engagement behaviour
  • Warning messages related to Haldex or traction system
Diagnostic Tip Similar symptoms can also be caused by ECU faults, pump problems, wiring issues or contamination inside the Haldex unit, so the N373 valve should be diagnosed as part of the full AWD system rather than by fault code alone. [web:181][web:182][web:188]

Installation & Service Notes

Recommended Steps

  • Verify the OEM number on the original N373 valve
  • Confirm that the vehicle uses a 4th generation Haldex system
  • Inspect the Haldex unit for contamination or related hydraulic faults
  • Install the replacement valve carefully and keep the component clean
  • Check electrical continuity and system operation after installation
  • Confirm AWD function with diagnostic equipment and road test if required
Important Service Note The N373 valve is a sensitive precision component. Rough handling, dirt contamination or incorrect diagnosis can lead to repeat AWD problems even after replacement. [web:182]

Why the N373 Valve Matters

1. Oil Control

The valve regulates internal oil flow paths inside the Haldex coupling.

2. Clutch Operation

It supports correct clutch operating angle behaviour and controlled AWD response.

3. AWD Performance

Correct valve operation helps the Haldex system engage and release the rear axle properly.

4. System Reliability

A properly functioning N373 valve helps reduce oil control faults and supports stable Haldex operation.

Quality Assurance & Warranty

12-Month Warranty: This used original Haldex control valve is supplied with a 12-month functionality warranty under normal operating conditions. [web:179]

Warranty Coverage Includes:

  • Functional defects of the supplied valve
  • Electrical or mechanical defects of the valve itself
  • Material defects under normal use

Warranty Exclusions:

  • Incorrect installation
  • Damage caused by contaminated oil or neglected Haldex service
  • AWD faults caused by pump, ECU, wiring or other unrelated components
  • Physical damage or misuse

Questions or Need Help?

Our technical team is ready to assist with compatibility checks, installation guidance and product selection.

Contact Us

Important Purchase Information

  • Please verify this part fits your specific vehicle before placing an order
  • The exact OEM number is more important than model name alone
  • Photos are for illustrative purposes only
  • Worldwide shipping is available
  • If your country is not listed at checkout, contact us and the order can be processed manually
